Reinforced Heavy Duty Steel GratingOptimized For Load Bearing And Drainage Applications
| Place of Origin | Hebei Province,China |
|---|---|
| Brand Name | Luo Jie |
| Certification | ISO9001 |
| Model Number | LJ-08 |
| Minimum Order Quantity | 50Pcs |
| Price | $5-26/pc |
| Packaging Details | by steel pallet |
| Delivery Time | 5-10days |
| Payment Terms | L/C,T/T |
| Supply Ability | 5000Pcs Per Month |
Product Details
| Material: | High-strength Low-carbon Steel, Stainless Steel, Or Hot-dip Galvanized Steel | Grating Type: | Available In Welded Or Hinged Structures, Offering Flexible Design And Application Options |
|---|---|---|---|
| Load-Bearing Capacity: | Reinforced Steel Grating Design Capable Of Withstanding Up To 1000 Kg/m² Load | Mesh Aperture: | Standard Aperture Sizes Of 30×30 Mm, 40×40 Mm, Or 50×50 Mm |
| Surface Finish: | Hot-dip Galvanized, Powder-coated, Or Stainless Steel Surfaces | Installation Method: | Supports Standard Frame, Bracket, Or Flange Fixing Methods For Easy And Quick Installation |
| Corrosion Resistance: | Especially Suitable For Coastal Areas, Chemical Plants, And Other Corrosive Environments | Packing & Delivery: | Palletized Flat Packing + Moisture-proof Wrap |
| Highlight: | reinforced metal grating,reinforced steel grating,heavy duty metal grating |
||
Product Description
Heavy-Duty Steel GratingOptimized for Load-Bearing and Drainage Applications
Product Overview
The Heavy-Duty Steel Grating is designed for applications that require high load-bearing capacity and excellent drainage performance. It is commonly used in industrial platforms, walkways, drainage channels, and other heavy-duty applications where strength, durability, and ease of maintenance are critical. Made from high-strength low-carbon steel, stainless steel, or hot-dip galvanized steel, the grating offers both robustness and corrosion resistance, making it ideal for outdoor and high-traffic environments.
Construction & Features
This steel grating features a welded or hinged structure, depending on the specific application. The standard mesh sizes, such as 30×30 mm, 40×40 mm, and 50×50 mm, are ideal for preventing debris buildup while allowing efficient water drainage. The welded construction ensures uniform load distribution across the surface, while the hinged option provides flexibility for use in specific areas where regular access is required.
Applications & Advantages
Heavy-duty steel grating is used in a variety of settings, including walkways, platforms, drain covers, industrial floors, and more. Its ability to handle heavy loads and high foot traffic makes it perfect for use in factories, warehouses, chemical plants, parking lots, and oil rigs. The corrosion-resistant properties, particularly when hot-dip galvanized or made from stainless steel, ensure long-lasting performance in harsh environmental conditions. Additionally, the grating's design offers easy maintenance by allowing debris and water to pass through without clogging.
Specification:
|
Model
|
Material
|
Bar Size (Width×Thickness)
|
Spacing (Bar×Cross Bar)
|
Load Capacity
|
Surface Treatment
|
Applicable Market
|
|
G253/30/100
|
Q235 Steel
|
25mm×3mm
|
30mm×100mm
|
≥45kN/m²
|
Hot-Dip Galvanization
|
North America, Middle East
|
|
G325/30/100
|
Q345 Steel
|
32mm×5mm
|
30mm×100mm
|
≥50kN/m²
|
Hot-Dip Galvanization
|
Heavy Industry (Mining)
|
|
G203/40/100
|
Q235 Steel
|
20mm×3mm
|
40mm×100mm
|
≥30kN/m²
|
Hot-Dip Galvanization
|
Europe, Southeast Asia
|
|
SS304-325/30/100
|
SS304 Steel
|
32mm×5mm
|
30mm×100mm
|
≥48kN/m²
|
Polishing
|
Chemical Plants
|
Installation & Maintenance
The grating is easy to install, thanks to its flat design and simple fixing mechanisms. It can be attached to steel frames, concrete supports, or other mounting structures using bolts or clamps. Regular inspection and cleaning are recommended to ensure maximum lifespan. The open design of the grating allows for easy removal of dirt and debris, reducing the need for frequent maintenance.
