Clean Scenery Guardrail 358 Security Fencing with Barbed Wire 6*10ft
| Place of Origin | Hebei Province,China |
|---|---|
| Brand Name | LJ |
| Certification | ISO9001:2015 |
| Model Number | LJ-02 |
| Minimum Order Quantity | 50 Sets |
| Price | $6.5-10.9 per square meter |
| Packaging Details | steel pallet or as your demand |
| Delivery Time | 7-15 days according to the quantity |
| Payment Terms | T/T |
| Supply Ability | 1000 sets per day |
Product Details
| Product Name: | 358 Security Fence / Welded Fence Panel | Key Word: | Anti-climb Anti-cut Fence |
|---|---|---|---|
| Material: | Low Carbon Steel | Wire Diameter: | 4.0mm |
| Mesh Hole: | 76.2*12.7mm | Panel Height: | 1-2.5m Or Customized |
| Panel Width: | 1-3m Or Customized | Surface Treatment: | Galvanized+PVC Coated, Hot-dipped Galvanized |
| Feature: | Small Mesh Aperture, Anti-cut, Anti-climb, Finger-resistant | Application: | Airport Security Fencing, Private Field Fence. |
| Port Of Loading: | Xingang Port | ||
| Highlight: | 358 security fence with barbed wire,clean scenery guardrail fencing,6x10ft security fence panel |
||
Product Description
Clean Scenery Guardrail 358 Security Fencing with Barbed Wire 6*10ft
Description of 358 Security Fence
1. Mesh Configuration: 3" × 0.5" (76.2mm × 12.7mm) rectangular mesh, anti-climb design with small vertical openings.
2. Wire Gauge: 8 gauge (4.0mm) high-tensile steel wire, hot-dip galvanized or PVC-coated.
3. Panel Dimensions: Standard height 6ft/8ft (1.8m/2.4m), length 10ft/12ft (3.05m/3.66m); custom sizes available.
4. Material: Low-carbon steel (Q235/Q195) or stainless steel (304/316) for corrosion resistance.
5. Surface Treatment: Hot-dip galvanization (min. 85μm coating thickness) or PVC powder coating (100-120μm, RAL colors optional).
6. Tensile Strength: ≥350MPa (steel wire), ensuring structural stability under impact.
7. Weight: 18-25kg per panel (varies by size and coating type).
8. Connection: Panel-to-post connection via M8/M10 bolts with anti-theft nuts; posts spaced 3.05m/3.66m apart.
9. Application: High-security areas (prisons, airports, power plants, data centers) due to anti-cut/anti-climb features.
Specifications of 358 Security Fence
| Specification of 358 Security Fence | |||||
| Mesh Opening | Wire Diameter | Panel Height | Panel Width | Post Type | |
| 12.7x76.2mm (0.5'' x 3'') |
3/3.5/4mm | 1.2-6m | 2.0-3.1m | Square Post(SHS) 60x60x2.0/2.5/3.0mm 80x80x2.0/2.5/3.0mm |
Rectangular Post(RHS) 40x60x2.0/2.5/3.0mm 40x80x2.0/2.5/3.0mm 60x80x2.0/2.5/3.0mm 80x100x2.0/2.5/3.0mm |
| Surface treatment:hot dipped galvanized, galvanized +powder coated, galvanized +PVC coating. | |||||
| Color:RAL 6005 green, RAL 7016 gray, All RAL color can be customized. | |||||
| Note:The fence can be customized according to your required if above specification is not satisfied with you. | |||||
Features of 358 Security Fence
· Good viewing visibility, it is a type of high security clear view fencing.
· Welded well at each intersection.
· Intrusion resistant, with extremely strong double vertical wire design.
· Small mesh aperture, anti-cut, anti-climb, finger-resistant and toe-resistant.
· Corrosion resistant with zinc aluminum alloy and PVC powder coating.
· Surface finish after welding, every weld-point are protected well.
· High strength with fully integrated with posts and anti-tamper fixings.
· Fence security toppings are optional.
· Easy for installation and free maintenance.
· 5 year warranty.
Applications of 358 Security Fence
- Bridge anti-climb guarding & guard safety screening
- Psychiatric hospital security fencing
- Prison security fencing
- Factory machine guards
- Walkway security fencing
- Airport security fencing
- Shipping Port Security fencing
- Electrical sub-station fencing
- Gas pipelines security fence
- High security living area and private field fence.
