Anti Climb Razor Wire Coil Galvanized Durable High Security Barrier
| Place of Origin | Hebei Province,China |
|---|---|
| Brand Name | Luo Jie |
| Certification | ISO9001:2015 |
| Model Number | LJ-13 |
| Minimum Order Quantity | 50 Sets |
| Price | $8.5-10.9 per meter |
| Packaging Details | Wooden Pallet,steel pallet |
| Delivery Time | 7-14days according to the quantity |
| Payment Terms | T/T |
| Supply Ability | 1000 sets per day |
Product Details
| Security Role: | Perimeter Intrusion Prevention, Anti-Climb Barrier | Installation Feature: | Preformed Coil With Quick-Lock Clips For Fast Mounting |
|---|---|---|---|
| Material: | Galvanized Steel / Stainless Steel Option | Blade Type: | Single Edge / Double Edge / Concertina (Coil) |
| Wire Gauge: | 2.0 Mm – 4.0 Mm Core Wire (customizable) | Coil Diameter: | 450 Mm – 1200 Mm (various Coils Available) |
| Tensile Strength: | ≥ 500 N / Mm² (depends On Wire Spec) | Surface Treatment: | Hot-Dip Galvanized / Galfan / PVC Coated |
| Highlight: | razor wire coil galvanized,anti climb razor wire coil,galvanized razor coil barbed wire |
||
Product Description
Anti Climb Razor Wire Coil Galvanized Durable High Security Barrier
Product Details:
Security Functionality & Design Philosophy
Razor wire (knife-edged barbed wire) is engineered primarily as an active deterrent for perimeter protection. Our Anti Climb Razor Wire Coil uses sharp, consistently punched blades arranged on a strong core wire and formed into compact coils or concertina arrays. The geometry of the blades and the coil spacing are optimized to discourage climbing, delay intruders, and provide a visible physical barrier for sites such as industrial estates, correctional facilities, military perimeters, and critical infrastructure.
Materials, Manufacturing & Key Specs:
Manufactured by precision punching and twisting processes, the product is available in galvanized steel for economical durability and in stainless steel for corrosive or marine environments. Blade profiles include single-edge and double-edge options; concertina coils provide rapid deployment with minimal hardware. Typical wire core gauges range from 2.0 mm to 4.0 mm; coil diameters are commonly 450 mm, 750 mm and 1200 mm. Tensile strength and surface coating options (hot-dip galvanizing, Galfan, or PVC) are selectable to meet operating conditions and longevity targets.
| Item | Specification |
|---|---|
| Material | Galvanized Steel / Stainless Steel |
| Blade Type | Single Edge / Double Edge / Concertina |
| Wire Gauge | 2.0 mm – 4.0 mm |
| Coil Diameter | 450 mm / 750 mm / 1200 mm (custom) |
| Tensile Strength | ≥ 500 N/mm² (typical) |
| Surface | Hot-Dip Galvanized / Galfan / PVC Coated |
Installation, Standards & Safety Considerations:
Designed for modular mounting, coils can be fixed to posts, walls, or atop fences using clips, brackets or welded supports. Preformed coils with quick-lock clips reduce labour time during installation. Note: installation must follow local safety and regulatory requirements; provide clear signage and restricted-area marking where required. We supply fixing kits, engineering drawings, and guidance for anchoring to ensure stable, code-compliant installations.
Packaging, MOQ & After-Sales Support:
Products are wrapped with protective film and secured on wooden pallets or in crates for export. Typical MOQ: 500 meters equivalent (or by coil unit) — negotiable for project orders. Lead time depends on specification and quantity (typically 10–30 days). We provide sample coils for inspection, project quotes including CAD layout assistance, and a manufacturing-defect warranty. Contact us for project support and custom quotations.
Contact us for samples, mounting kits, and a site-specific quotation — send your project drawing now.
